Rolland Rollforce Muck Spreaders
Machine Information
Machine Information
- Available to order
- Finance options available
- Part exchange considered
- Delivery available
- Contact us for current lead times
Request a Quote
Request a Quote
Looking for pricing, finance options or additional specifications? Click the Request a Quote button above and our team will be in touch.
Description
Description
PRICE ON APPLICATION
Choose your model and tell us the job it needs to do. We will confirm specification, availability and delivery with your quotation.
Agricultural manure spreaders with several body lengths and capacities. Ask us about vertical-beater and TCEi spreading-table configurations, tractor requirements and the materials you intend to spread.
Compare models | Model specifications | Brochures
Compare the models
Swipe or scroll across the table on smaller screens.
| Model | Length | Width | Capacity | Running gear |
|---|---|---|---|---|
| Rollforce 5013 | 5000 mm | 1460 mm | Volume: 13 m3 | 1 axle |
| Rollforce 5514 | 5500 mm | 1460 mm | Volume: 14 m3 | 1 axle |
| Rollforce 5517 | 5500 mm | 1460 mm | Volume: 17 m3 | 1 axle |
| Rollforce 6115 | 6100 mm | 1460 mm | Volume: 15 m3 | 1 axle |
| Rollforce 6118 | 6100 mm | 1460 mm | Volume: 18 m3 | 1 axle |
| Rollforce 6616 | 6600 mm | 1460 mm | Volume: 16 m3 | 1 axle |
| Rollforce 6620 | 6600 mm | 1460 mm | Volume: 20 m3 | 1 axle |
| Rollforce 7322 | 7300 mm | 1460 mm | Volume: 22 m3 | 2 fix axles or steering tandem |
Figures are manufacturer-listed and configuration dependent. Volume is not a weight payload. Body extensions, tyre sizes and selected options can change dimensions and usable capacity. Confirm the final UK specification with your quotation.
Specifications by model
Open a model below to see its published technical details.
Rollforce 5013 — specifications
| Body length | 5000 mm |
|---|---|
| Body width | 1460 mm |
| Side height | 1230 mm |
| Manufacturer-listed volume | 13 m3 |
| Axle / running gear | 1 axle |
| Brakes | Dual line air or oil |
| Wheels | Various models on the catalogue |
| Drawbar | Triangulated springs or hydraulic |
| Jack | Simple hydraulic or LIFT |
| Bed-floor chains | 2x16 |
| Spreading deck | Vertical beaters ESP21 or table spreading TCEi |
| Buzzer | Yes |
Rollforce 5514 — specifications
| Body length | 5500 mm |
|---|---|
| Body width | 1460 mm |
| Side height | 1230 mm |
| Manufacturer-listed volume | 14 m3 |
| Axle / running gear | 1 axle |
| Brakes | Dual line air or oil |
| Wheels | Various models on the catalogue |
| Drawbar | Triangulated springs or hydraulic |
| Jack | Simple hydraulic or LIFT |
| Bed-floor chains | 2x16 |
| Spreading deck | Vertical beaters ESP21 or table spreading TCEi |
| Buzzer | Yes |
Rollforce 5517 — specifications
| Body length | 5500 mm |
|---|---|
| Body width | 1460 mm |
| Side height | 1550 mm |
| Manufacturer-listed volume | 17 m3 |
| Axle / running gear | 1 axle |
| Brakes | Dual line air or oil |
| Wheels | Various models on the catalogue |
| Drawbar | Triangulated springs or hydraulic |
| Jack | Manual Jack or hydraulic |
| Bed-floor chains | 2x16 |
| Spreading deck | Vertical beaters ESP21 / ESP25 or table spreading TCEi |
| Buzzer | Yes |
Rollforce 6115 — specifications
| Body length | 6100 mm |
|---|---|
| Body width | 1460 mm |
| Side height | 1230 mm |
| Manufacturer-listed volume | 15 m3 |
| Axle / running gear | 1 axle |
| Brakes | Dual line air or oil |
| Wheels | Various models on the catalogue |
| Drawbar | Triangulated springs or hydraulic |
| Jack | Simple hydraulic or LIFT |
| Bed-floor chains | 2x16 |
| Spreading deck | Vertical beaters ESP21 or table spreading TCEi |
| Buzzer | Yes |
Rollforce 6118 — specifications
| Body length | 6100 mm |
|---|---|
| Body width | 1460 mm |
| Side height | 1550 mm |
| Manufacturer-listed volume | 18 m3 |
| Axle / running gear | 1 axle |
| Brakes | Dual line air or oil |
| Wheels | Various models on the catalogue |
| Drawbar | Triangulated springs or hydraulic |
| Jack | Simple hydraulic or LIFT |
| Bed-floor chains | 2x16 |
| Spreading deck | Vertical beaters ESP21 / ESP25 or table spreading TCEi |
| Buzzer | Yes |
Rollforce 6616 — specifications
| Body length | 6600 mm |
|---|---|
| Body width | 1460 mm |
| Side height | 1230 mm |
| Manufacturer-listed volume | 16 m3 |
| Axle / running gear | 1 axle |
| Brakes | Dual line air or oil |
| Wheels | Various models on the catalogue |
| Drawbar | Triangulated springs or hydraulic |
| Jack | Simple hydraulic or LIFT |
| Bed-floor chains | 2x16 |
| Spreading deck | Vertical beaters ESP21 or table spreading TCEi |
| Buzzer | Yes |
Rollforce 6620 — specifications
| Body length | 6600 mm |
|---|---|
| Body width | 1460 mm |
| Side height | 1550 mm |
| Manufacturer-listed volume | 20 m3 |
| Axle / running gear | 1 axle |
| Brakes | Dual line air or oil |
| Wheels | Various models on the catalogue |
| Drawbar | Triangulated springs or hydraulic |
| Jack | Simple hydraulic or LIFT |
| Bed-floor chains | 2x16 |
| Spreading deck | Vertical beaters ESP21 / ESP25 or table spreading TCEi |
| Buzzer | Yes |
Rollforce 7322 — specifications
| Body length | 7300 mm |
|---|---|
| Body width | 1460 mm |
| Side height | 1550 mm |
| Manufacturer-listed volume | 22 m3 |
| Axle / running gear | 2 fix axles or steering tandem |
| Brakes | Dual line air or oil |
| Wheels | Various models on the catalogue |
| Drawbar | Triangulated springs or hydraulic |
| Jack | Simple hydraulic or LIFT |
| Bed-floor chains | 2x16 |
| Spreading deck | Vertical beaters ESP21, ESP25 or spreading table TCEi |
| Buzzer | Yes |
Manufacturer brochures
Choose the right specification
Send us the model, your tractor make and model, intended material or load, required options and delivery postcode. We will confirm hitch and braking compatibility, current availability, the final equipment specification and delivery arrangements before an order is agreed.
Manufacturer photographs illustrate the range and may show optional equipment. This listing does not indicate that every model is held in stock.
