LWC | SKU:
ASP-LWC-TINES
LWC Replacement Attachment Tines
Regular price
POA – Contact us for pricing
Machine Information
Machine Information
- Available to order
- Finance options available
- Part exchange considered
- Delivery available
- Contact us for current lead times
Request a Quote
Request a Quote
Looking for pricing, finance options or additional specifications? Click the Request a Quote button above and our team will be in touch.
Description
Description
Replacement attachment tines from LWC. Provide the attachment model, tine measurements and mounting details with your enquiry.
Price on application. Request a quotation from Agri Service Parts for the selected model, options and delivery. Availability and lead time will be confirmed with your quote.
Manufacturer model specifications
| Model | Tine | Length | Type | Conus | Thread |
|---|---|---|---|---|---|
| TIN-0003 | SHW | 680mm | Straight | C1 | M20 |
| TIN-0004 | SHW | 820mm | Straight | C1 | M20 |
| TIN-0006 | SHW | 820mm | Straight | C1 | M24 |
| TIN-0009 | SHW | 820mm | Straight | C2 | M28 |
| TIN-0011 | SHW | 980mm | Straight | C2 | M28 |
| TIN-0007 | SHW | 1100mm | Straight | C2 | M28 |
| TIN-0008 | SHW | 1240mm | Straight | C2 | M28 |
| TIN-0016 | SHW | 1400mm | Straight | C2 | M28 |
| TIN-0001 | SHW | 600mm | Curved | C1 | M20 |
| TIN-0002 | SHW | 680mm | Curved | C1 | M20 |
| TIN-0024 | SHW | 810mm | Curved | C2 | M28 |
| TIN-0010 | SHW | 980mm | Curved | C2 | M28 |
| TIN-0005 | SHW | 820mm | Cranked | C1 | M24 |
| TIN-0012 | HARDOX | 40 x 928mm | Curved | N/A | N/A |
| TIN-0013 | HARDOX | 40 x 800mm | Straight | N/A | N/A |
| TIN-0014 | HARDOX | 40 x 1065mm | Straight | N/A | N/A |
| TIN-0015 | HARDOX | 40 x 1400mm | Straight | N/A | N/A |
| TIN-0019 | HARDOX | 40 x 570mm | Curved | N/A | N/A |
| TIN-0028 | HARDOX | 40 x 550mm | Straight | N/A | N/A |
Model options and specifications depend on configuration. Please tell us the machine make, model and bracket or linkage type where applicable. Compatibility, delivery arrangements and the final specification must be confirmed before ordering.
